Standard PCB Capabilities

Standard PCB Capabilities

Item Capability
Maximum Layer Count 50
Thickness Range 0.06 - 5.6 mm
Min Outer Layer Line Width/Space 3/3 mil
Max Outer Layer Copper Thickness 30 oz
Max Inner Layer Copper Thickness 15 oz
Aspect Ratio 20:01
Mechanical Drill Range 0.15 - 6.5 mm
Mechanical Hole Position Tolerance +/- 0.05 mm
Outline Tolerance +/- 0.05 mm
Soldermask Dams Width Min 0.075 Green, 0.125 mm Other Colors
Impedance Tolerance 50 ohms +/- 10%
Surface Treatments HASL, LFHASL, ENIG, ENEPIG, Immersion Silver, Immersion Tin, OSP, Hard Gold Fingers, Carbon Ink, Peelable Mask
Special Processes POFV, Buried/Blind Vias, Back-Drilling. Controlled Depth Milling, Hybrid Materials, Counterbore, Copper Via Plugging
PRODUCT PARAMETERS PRESENTLY 2025 2026
Multi-layer Minimum Line Width (mils) 3.0/3.0 2.5/2.5 2.5/2.5
Line Width Tolerance (mils) +/- 0.8 +/- 0.5 +/- 0.5
Layers (max) 50 56 60
Aspect Ratio 20:1 (4.0/0.25) 22:1 (5.5/0.25) 24:1 (6.0/0.2)
Copper Max Outer Layer 30 oz 30 oz 30 oz
Max Inner Layer 15 oz 15 oz 15 oz
Blind/Buried Via Number of Pressing 3 3 4
Dimple PoFV (um) ≤ 75 ≤ 50 ≤ 25
HDI Blind Via Aspect Ratio 0.8:1 1:01 1:01
Via Plugging Aspect Ratio 0.8:1 0.8:1 0.8:1
HDI Steps 5 6, Any-Layer 6, Any-Layer
Rigid Flex Board Layers 12 16 18
Structure Books, Pontoons, Flying Tails Books, Pontoons, Flying Tails Books, Pontoons, Flying Tails
Conventional FR-4 S1141 / S1000H / S1000-2M
IT158 / IT180A
KB6160 / KB6165 / KB6167
TU768 / TU865
Halogen Free
S1150G / TU747T / TU862
High Frequency S7135 / S7136
RO3003 / RO4003 / RO4350B / RO4730G3 / RO5880
TLY-5 / TLX-6 / TLX-8 / RF30 / AD255 / AD3000C / F4B
High Speed TU872SLK / TU883 / TU933+ / M-4 / M-6 / M-7 / IT968 / IT988
High Thermal Conductivity High CTI ST115 / S1600L
Flexible PI:SF202 SF305 (Adhesive) / AP85 Series / AP91 Series / SF305C (Coverlay)
Download PDF
Download PDF

Assembly Capabilities

Inspecting/Testing

  • Class II Standard, Class III Upon Request
  • Visual Inspection
  • Automated Optical
  • Firmware Testing (Provided SOP and Testing Equipment)
Supported File Formats
  • CODB++, CAD ASCII, IPC-2581
  • BOM: .xls, .csv, .xlsx
  • Geber (RS-274X)l
  • Centroid (XY, Pick-n-Place)
Paste
  • Senju (Lead-Free)
  • Senju (Leaded)
Wire
  • AIM SN100C (Lead-Free)
  • AIM SAC305 (Leaded)
SMT Components Presentation
  • Cut Tape
  • Partial Reel
  • Full Real
  • Tube
  • Tray

Solder

  • No-Clean Flux is Standard
  • Selective Solder
  • Lead-Free (RoHS)
  • Leaded
Depanelization
BGA Rework

Washing Machine (Aqua Rose)

Box Building
Supported Part Specs
  • 2-Sided SMT
  • SMT Sizes: 01005 or Larger
  • Fine Pitch: 16mil (0.4mm) or Greater
  • BGA Pitch 16mil (0.4mm) or Greater
  • BGA Ball Count: Up to 1932. Call for Larger Parts
  • Max Size: 2.2in x 2.2in x 0.06in
Supported PC Board Specs
  • Min Size: 1.967in x 1.967in
  • Max Size: 19.67in x 19.67in
  • Min Thickness: 4mil
  • Max Thickness: 240mil
  • Layer Count: Up to 24
  • Finishes: HASL, ENIG, Silver, SMOBC/HAL, All Finishes Acceptable
  • Markings: Silkscreen, Solder Mask (Preferred)…not Required on PCB, Assembly Drawing Can Work as a Replacement for Silkscreen
  • Material: Rigid, Rogers 4000, Flex, Rigid Flex, Metal Clad, Others

Assembly Capabilities

Inspecting/Testing

  • Class II Standard, Class III Upon Request
  • Visual Inspection
  • Automated Optical
  • Firmware Testing (Provided SOP and Testing Equipment)

Supported File Formats

  • CODB++, CAD ASCII, IPC-2581
  • BOM: .xls, .csv, .xlsx
  • Geber (RS-274X)
  • Centroid (XY, Pick-n-Place)

Paste

  • Senju (Lead-Free)
  • Senju (Leaded)

Wire

  • AIM SN100C (Lead-Free)
  • AIM SAC305 (Leaded)

SMT Components Presentation

  • Cut Tape
  • Partial Reel
  • Full Real
  • Tube
  • Tray

Solder

  • No-Clean Flux is Standard
  • Selective Solder
  • Lead-Free (RoHS)
  • Leaded

Depanelization

Available

BGA Rework

Available

Washing Machine (Aqua Rose)

Available

Box Building

Available

Supported Part Specs

  • 2-Sided SMT
  • SMT Sizes: 01005 or Larger
  • Fine Pitch: 16mil (0.4mm) or Greater
  • BGA Pitch 16mil (0.4mm) or Greater
  • BGA Ball Count: Up to 1932. Call for Larger Parts
  • Max Size: 2.2in x 2.2in x 0.06in

Supported PC Board Specs

  • Min Size: 1.967in x 1.967in
  • Max Size: 19.67in x 19.67in
  • Min Thickness: 4mil
  • Max Thickness: 240mil
  • Layer Count: Up to 24
  • Finishes: HASL, ENIG, Silver, SMOBC/HAL, All Finishes Acceptable
  • Markings: Silkscreen, Solder Mask (Preferred)…not Required on PCB, Assembly Drawing Can Work as a Replacement for Silkscreen
  • Material: Rigid, Rogers 4000, Flex, Rigid Flex, Metal Clad, Others
